High-Temperature Solenoid Valves: Overview, Features, Scope & Parameters

1. Product Overview

High-temperature solenoid valves are used in various medium-temperature, high-temperature, normal-pressure, and high-pressure occasions. They are suitable for the automatic control of pipelines carrying medium-high temperature hot water, high-temperature steam, saturated steam, superheated steam, heat transfer oil, etc.

Widely applied in industries such as kiln equipment, drying equipment, petrochemicals, biopharmaceuticals, HVAC, electroplating and coating, rubber and plastic machinery, food and beverage, papermaking, printing and dyeing, as well as power and mining industries, they are the preferred products for automatic control projects, project transformation, and equipment supporting.

2. Product Features

• Continuous Long-Term Energization: Capable of continuous long-term energization in special occasions, adopting all-metal sealing. The maximum medium temperature can reach 350℃-450℃.

• Targeted Sealing: Customized sealing solutions for different media, enhancing the rationality of the solenoid valve.

• Compact Structure: Equipped with an innovative and ingenious valve core structure and heat dissipation device, resulting in a more compact design—weighing only one-third of similar products.

• Durable Piston Structure: Adopts a stainless steel piston structure with automatic compensation for valve core wear, significantly improving service life and reliability, and enabling continuous frequent operation.

• High Pressure Adaptation: The maximum medium pressure can be 2.5Mpa-4.0Mpa (customizable).

3. Application Scope

Aerospace, marine heavy industry, petrochemicals, power equipment, biopharmaceuticals, industrial kilns, brewing, drying equipment, HVAC, electroplating and coating, food industry, thermal power plants, rubber and plastic machinery, etc.

4. Technical Parameters
