Low-Pressure Solenoid Valves
Product Overview of Low-Pressure Solenoid Valves
Low-pressure solenoid valves are automatic control devices widely used in fluid control systems. Controlled by an electromagnetic coil to open and close the valve, they can precisely regulate fluid flow and are extensively applied in pipeline systems for media such as gases, liquids, and steam. Specifically suitable for systems that do not require high pressure resistance, low and medium pressure solenoid valves can efficiently control fluid flow with high reliability and safety.
Technical Parameters of Low-Pressure Solenoid Valves
Parameter Category | Specifications |
|---|---|
Product Specification | DN1~DN1000 |
Valve Body Material | Cast iron, stainless steel (note: cast iron is not suitable for corrosive fluids) |
Applicable Medium | Gases, water, oil, steam, gas, corrosive fluids |
Medium Temperature | 0~100℃ |
Medium Viscosity | <50CSt (customization required when viscosity >50CSt) |
Protection Performance | Waterproof, explosion-proof (Exd IICT5), corrosion-resistant |
Valve Core Material | All stainless steel |
Wiring Method | Terminal block type, lead wire type, plug type |
Control Mode | Normally Open (NO), Normally Closed (NC) |
Power Supply Voltage | DC12~127V; AC36~380V |
Connection Method | Internal thread, flanged (external thread and special interfaces are customizable or available with adapters) |
Leakage | Zero |
