The socket weld forged steel globe valve is suitable for small-diameter pipelines with Class 150～2500 and operating temperature of -29～425℃ (carbon steel) or -29～500℃ (stainless steel). It is used to cut off or connect the medium in the pipeline. By selecting different materials, it can be applied to various media such as water, steam, oil products, acetic acid, oxidizing media, and urea. The forged steel gate valve has small fluid resistance, a wide applicable pressure and temperature range, no restriction on the flow direction of the medium, and good sealing performance.

Features of Socket Weld Forged Steel Globe Valve

1. Compact structure, reliable performance and exquisite appearance;

2. Adopting forged steel valve body and PTFE (polytetrafluoroethylene) engineering plastic sealing ring;

3. High pressure resistance, good sealing performance, and flexible and comfortable handle movement;

4. The sealing surfaces of the valve core and valve seat are quenched, which are not easy to wear or scratch under high temperature and high pressure, with good sealing performance and long service life;

5. The valve bonnet is designed with two 90° sealing conical surfaces. The combination of conical surface 1 and the sealing ring forms a double seal to prevent fluid leakage;

6. When the valve is fully open, conical surface 2 is wedged with the conical surface on the valve stem to prevent the medium from flowing to the packing.
